CP-45F-50LS
DXF
PDF
CP-45F-150LS, -200LS
DXF
PDF
  • Linear stroke 500~2000mm

CP-45F-LS Series

Product specifications

  CP-45F-50LS CP-45F-150LS CP-45F-200LS
Features High Accuracy
Total Resistance 0.5, 1, 2, 5, 10, 20kΩ
Effective Electrical Travel 610mm 1,640mm 2,235mm
Independent Linearity ±0.1%FS
Rated Dissipation 3W/70℃
Dimension 60x104mm

*If you need something different from our standard models, please contact us.



[Applications]

Civil Enginnering Machine:Control/Position

Manufacturing Machinery:Control/Hydraulic Cylinder stroke

Lifter:Control/Lifting position

Monitoring Instruments for Natural disasters:Monitor/Landslide,Debris flow, Dam break

TSUNAMI Wave Height Measuring Instrument:Control/Wave height
