PMP-xxHTL
DXF
PDF
  • Drip proof
  • Include angle 10°~90°

PMP-xxHTL Series

Product specifications

  PMP-10HTZL PMP-5HTZL PMP-20HTZL PMP-30HTZL
 Features Drip-proofRobust, Built-in PMP-SxxHT sensor, Dual Axis
Electrical Tilt Angle ±10° ±5° ±20° ±30°
Center Based Linearity ±1%FS
Input Voltege DC5V
Dimension 49x92x60mm

[Option]
Other dumper oil viscosity
Narrower output voltage range
Different electrical tilt angle between X and Y axis
Single Axis
*If you need something different from our standard models, please contact us.

[Applications]

Large Dump Truck:Control/Truck position,Rated load

Excavator:Control/Body position

Aerial Work Platform:Control/Platform position

Pile Driver:Control/Pile position

Ground Surface Inclinometer:Measurement/Landslide,Debris flow

Container vessel:Control/Heel trim angle





Part numbers
